Yanmar EF330J
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Yanmar EF330J Engine | |
| Yanmar 1.5L 3-cyl diesel | |
| Fuel tank | 9.5 gal 36.0 L |
 Engine details ... | |
| Yanmar EF330J Transmission | |
| 20-speed four-speed power shift | |
 Transmission details ... |
| Yanmar EF330J Power | |
| Engine | 29.6 hp 22.1 kW |
| Mechanical | |
| Four-wheel drive |
| Photos | |
| No photos of the Yanmar EF330J are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Rear lift | 3307 lbs 1500 kg |
| Power Take-off (PTO) | |
| Rear PTO | 540 (1.375) |
| Engine RPM | 568@2700 |
| 784@2700 | |
| 991@2700 | |
| 1296@2700 | |
| -623@2700 | |
| Dimensions & Tires | |
| Wheelbase | 70.9 inches 180 cm |
| Weight | 3285 to 3638 pounds |
| Front tire | 8-16 |
| Rear tire | 12.4-26 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| EF300 Series (41812-011884) published in 2004 |
