Yanmar EF326


No photo available
2002 - 2004
EF300 Series
Compact Utility tractor
Series map:
EF324
EF326
EF328
17.7kw
19.1kw
20.6kw
Production
ManufacturerYanmar
Compact Utility tractor
Variants
EF326QCab
Yanmar EF326 Engine
Yanmar 1.5L 3-cyl diesel
Fuel tank7.1 gal
26.9 L
Engine details ...
Yanmar EF326 Power
Engine25.6 hp
19.1 kW
Mechanical
Four-wheel drive
Photos
No photos of the Yanmar EF326 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Rear lift3307 lbs
1500 kg
Power Take-off (PTO)
Rear PTO540 (1.375)
Engine RPM547@2600
 755@2600
 955@2600
 1248@2600
 -600@2600
Dimensions & Tires
Wheelbase64.6 inches
164 cm
Weight2954 to 3351 pounds
Front tire7-16
Rear tire11.2-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
EF326 references literature
EF300 Series (41812-011884) published in 2004
