CaseIH Farmall 45C Series II
|
|
| Production | |
| Manufacturer | CaseIH |
| Compact Utility tractor | |
| Original price | $30,061 (2020 shuttle ROPS ) |
| $37,113 (2020 hydro Cab ) | |
| CaseIH Farmall 45C Engine | |
| LS Mtron 1.9L 3-cyl diesel | |
| ROPS Fuel tank | 10.6 gal 40.1 L |
| Cab Fuel tank | 12.4 gal 46.9 L |
 Engine details ... | |
| CaseIH Farmall 45C Transmissions | |
| 16-speed mechanical shuttle | |
| hydrostatic | |
 Transmission details ... |
| CaseIH Farmall 45C Power | |
| Engine | 45 hp 33.6 kW |
| Gear PTO (claimed) | 38.2 hp 28.5 kW |
| Hydro PTO (claimed) | 36 hp 26.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet multi disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Farmall 45C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 1 or 2 |
| Pump flow | 8.2 gpm 31.0 lpm |
| Gear Steering flow | 4.2 gpm 15.9 lpm |
| Hydro Steering flow | 5.3 gpm 20.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 2756 lbs 1250 kg |
| Rear lift (at 24"/610mm) | 2469 lbs 1119 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 73.2 inches 185 cm |
| Weight | 3770 to 4453 pounds |
| Front tire | 9.5x16 |
| Rear tire | 13.6x24 |
 Full dimensions and tires ... | |
| CaseIH Farmall 45C attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 70 |
| Battery volts | 12 |
| References | |
 | |
| Farmall Compact C Series II published in 2019, by CaseIH |
