Tractors > John Deere > 5425

John Deere 5425



John Deere 5425 tractor photo
2006 - 2012
5025 Series
Utility tractor
Series map:
5425
5625
57.4kw
60.4kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Saltillo, Mexico
Variants
5425Oorchard
5425HChigh-crop
John Deere 5425 Engine
John Deere 4.6L 4-cyl diesel
Fuel tank25 gal
94.6 L
Engine details ...
John Deere 5425 Transmission
9-speed gear
Transmission details ...
John Deere 5425 Power
Engine77 hp
57.4 kW
PTO (claimed)66 hp
49.2 kW
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post fixed ROPS. Foldable ROPS optional.
Photos
No photos of the John Deere 5425 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2800 psi
193.1 bar
Pump flow15.9 gpm
60.2 lpm
Steering flow6.6 gpm
25.0 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Controltop-link draft sensing
Rear lift (at 24"/610mm)3374 lbs
1530 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2400
 540E@1700
Dimensions & Tires
Wheelbase83.7 inches
212 cm
Weight5470 to 5886 pounds
Front tire7.5x16
2WD Rear tire15.5x38
Full dimensions and tires ...
5425 Serial Numbers
Location:Serial number plate on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Battery CCA550
Battery volts12
Battery Group27F
References
5425 references literature
Tractores Serie 5025 published in 2007, by John Deere
