Iseki TL4100
|
|
| Production | |
| Manufacturer | Iseki |
| Utility tractor | |
| Iseki TL4100 Engine | |
| Isuzu 2.0L 4-cyl diesel | |
| Fuel tank | 13.2 gal 50.0 L |
 Engine details ... | |
| Iseki TL4100 Power | |
| Engine | 40.4 hp 30.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Four-post ROPS with canopy. Open station available. |
| Photos | |
| No photos of the Iseki TL4100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 602@2600 |
| 734@2600 | |
| 959@2600 | |
| 1566@2600 | |
| Dimensions & Tires | |
| Wheelbase | 76.4 inches 194 cm |
| Weight | 3516 to 4012 pounds |
| Front tire | 6.00-16 |
| 2WD Rear tire | 13.6-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| TL published in 1984, by Iseki | |
| TL3700 - TL4100 - TL4500 |
