LS XG3025
| | 2016 - 2019 |
| XG Series | | Compact Utility tractor |
|
Series map:
XG3025
XG3135
24.4hp
35.0hp
| Production |
| Manufacturer | LS
|
| Compact Utility tractor |
| LS XG3025 Power |
| Engine (gross) | 24.4 hp
18.2 kW
|
| Gear PTO (claimed) | 19.2 hp
14.3 kW
|
| Hydro PTO (claimed) | 17.1 hp
12.8 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the LS XG3025 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pump flow | 7.9 gpm
29.9 lpm
|
| Total flow | 12.5 gpm
47.3 lpm
|
| Steering flow | 4.6 gpm
17.4 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 1808 lbs
820 kg
|
| Rear lift (at 24"/610mm) | 1433 lbs
650 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2509
|
| XG3025 Serial Numbers |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle.
|
| Electrical |
| Charging amps | 50
|
| Battery volts | 12
|
| References |
 |
| XG3000 Series published in 2016, by LS |
| XG3025 - XG3025H (52120001/00) published in 2015 |
