Kubota GL-530


Kubota GL-530 tractor photo
1995 - 1998
GL Series
Compact Utility tractor
Series map:
GL-470
GL-530
GL-600
35.0kw
39.5kw
44.7kw
Production
ManufacturerKubota
Compact Utility tractor
Kubota GL-530 Engine
Kubota 2.7L 5-cyl diesel
Fuel tank13.2 gal
50.0 L
Engine details ...
Kubota GL-530 Power
Engine53 hp
39.5 kW
Mechanical
Four-wheel drive
Power steering
Two-post ROPS. Cab optional.
Photos
No photos of the Kubota GL-530 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM585@2600
 789@2600
 961@2600
 1263@2600
 -789@2600
Dimensions & Tires
Wheelbase78.2 inches
198 cm
Weight3836 to 4317 pounds
Front tire8.3-20
Rear tire12.4-32
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
GL-530 references literature
GL (T0180-1921-7) published in 1995
