Mahindra Max 25XL
|
|
| Production | |
| Distributor | Mahindra |
| Manufacturer | TYM |
| Compact Utility tractor | |
| Original price was $16,730 in 2019 | |
| Mahindra Max 25XL Engine | |
| Mitsubishi 1.3L 3-cyl diesel | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Mahindra Max 25XL Power | |
| Engine | 24 hp 17.9 kW |
| PTO (claimed) | 20 hp 14.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
| No photos of the Mahindra Max 25XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 4.6 gpm 17.4 lpm |
| Total flow | 7.3 gpm 27.6 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 1354 lbs 614 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2376 |
| Mid PTO Type | 2000 |
| Engine RPM | 2000@2556 |
| Dimensions & Tires | |
| Wheelbase | 58.2 inches 147 cm |
| Weight | 1715 lbs 777 kg |
| Front tire | 6x12 |
| Rear tire | 9.5x16 |
 Full dimensions and tires ... | |
| Mahindra Max 25XL attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Battery CCA | 450 |
| Battery volts | 12 |
| References | |
 | |
| Max Series published in 2019, by Mahindra |
