Kubota M1-85
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M1-85 Engine | |
| Kubota 4.7L 4-cyl diesel | |
| Fuel tank | 27.7 gal 104.8 L |
 Engine details ... | |
| Kubota M1-85 Transmissions | |
| 12-speed | |
| 18-speed creeper | |
 Transmission details ... |
| Kubota M1-85 Power | |
| Engine | 85 hp 63.4 kW |
| PTO (claimed) | 79.9 hp 59.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Four-post ROPS. Cab optional. |
| Photos | |
| No photos of the Kubota M1-85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| JIS2 | |
| Rear lift | 6173 lbs 2800 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2035 |
| 1000@2389 | |
| Dimensions & Tires | |
| Wheelbase | 90.6 inches 230 cm |
| Weight | 6570 lbs 2980 kg |
| Front tire | 9.5-24 |
| Rear tire | 13.9-36 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| M1 published in 1991, by Kubota | |
| M1 (33760-9971-2) |
