Bobcat CT4050
|
|
| Production | |
| Distributor | Bobcat |
| Manufacturer | Daedong |
| Compact Utility tractor | |
| Original price was $25,105 in 2019 | |
| Bobcat CT4050 Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 11.9 gal 45.0 L |
 Engine details ... | |
| Bobcat CT4050 Transmissions | |
| 8-speed synchronized shuttle | |
| hydrostatic | |
 Transmission details ... |
| Bobcat CT4050 Power | |
| Engine | 50.3 hp 37.5 kW |
| Shuttle PTO (claimed) | 45.6 hp 34.0 kW |
| Gear PTO (claimed) | 39.3 hp 29.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
| No photos of the Bobcat CT4050 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 9.62 gpm 36.4 lpm |
| Total flow | 14.5 gpm 54.9 lpm |
| Steering flow | 4.94 gpm 18.7 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at 24"/610mm) | 2716 lbs 1231 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 71 inches 180 cm |
| Weight | 3373 to 3523 pounds |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Bobcat CT4050 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Compact Tractors published in 2020, by Bobcat |
