| | 1986 - 1989 |
| Orchard/Vineyard tractor |
|
Series map:
154S
174S
46.7hp*
63.3hp*
*Estimated engine power for comparison only.
| Transmission options |
| 12-speed partially synchronized |
| 20-speed creeper |
| Transmission |
| Type | partially synchronized
|
| Gears | 12 forward and 4 reverse
|
| Clutch | 279.4mm dry disc
|
| Oil capacity | 40 qts
37.9 L
|
| Four synchronized gears in three ranges, plus reverse range. |
| Speeds |
| With 14.9-24 rear tires. |
|
| Transmission |
| Type | creeper
|
| Gears | 20 forward and 8 reverse
|
| Clutch | dry disc
|
