John Deere 830



John Deere 830 tractor photo
1974 - 1979
Utility tractor
Series map:
830
930
26.1kw
32.1kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 830 Engine
John Deere 2.7L 3-cyl diesel
Engine details ...
John Deere 830 Transmission
8-speed gear
Transmission details ...
John Deere 830 Power
Engine (net)35 hp
26.1 kW
PTO (claimed)29.5 hp
22.0 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Manual steering
Wet disc brakes
Photos
No photos of the John Deere 830 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel16.4 gal
62.1 L
Hydraulic system7.9 gal
29.9 L
Hydraulics
Typeopen center
Capacity7.9 gal
29.9 L
Pressure2104 psi
145.1 bar
Pump flow6.3 gpm
23.8 lpm
Tractor hitch
Rear TypeI
Controlposition and draft control
Rear lift3417 lbs
1549 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchdry disc
Rear PTO Type540 (1.375)
Engine RPM540@2100
Dimensions & Tires
Wheelbase74.4 inches
188 cm
Weight4740 lbs
2150 kg
Front tire6.00-16
Rear tire13.6/12-28
Full dimensions and tires ...
830 Serial Numbers
Location:Serial number plate on the right side of the Deere 830 tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps28
Battery volts12
Battery AH55
References
830 references literature
Operator's Manual Tractors 830 and 930 (OML31437)
Operator's Manual Tractors 830 and 930 (OML33962)
Product Information Manual published in 1975, by John Deere
Product Information Manual published in 1977, by John Deere
