John Deere 930



John Deere 930 tractor photo
1974 - 1979
Utility tractor
Series map:
830
930
1030
26.1kw
32.1kw
36.0kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 930 Engine
John Deere 2.7L 3-cyl diesel
Engine details ...
John Deere 930 Transmission
8-speed gear
Transmission details ...
John Deere 930 Power
Engine (gross)43 hp
32.1 kW
Engine (net)41 hp
30.6 kW
PTO (claimed)34.9 hp
26.0 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Manual steering
Wet disc brakes
Photos
No photos of the John Deere 930 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel16.4 gal
62.1 L
Hydraulic system7.9 gal
29.9 L
Hydraulics
Typeopen center
Capacity7.9 gal
29.9 L
Pump flow6.3 gpm
23.8 lpm
Tractor hitch
Rear TypeI
Controlposition and draft control
Rear lift3417 lbs
1549 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Engine RPM540@2100
Dimensions & Tires
Wheelbase74.4 inches
188 cm
Weight4806 lbs
2180 kg
Front tire6.00-16
Rear tire13.6/12-28
Full dimensions and tires ...
930 Serial Numbers
Location:Serial number plate on the right side of the Deere 930 tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps28
Charging volts12
Batteries2
Battery volts12
Battery AH55
References
930 references literature
Operator's Manual Tractors 830 and 930 (OML31437)
Operator's Manual Tractors 830 and 930 (OML33962)
Product Information Manual published in 1975, by John Deere
Product Information Manual published in 1977, by John Deere
