Fiat G210
| | 1993 - 2002 |
| G Series | | Row-Crop tractor |
|
Series map:
G190
G210
G240
141.7kw
156.6kw
179.0kw
Note: the Fiat model G210 is the same as the Ford 8870. The following data is from the 8870 listing. |
| Production |
| Manufacturer | Fiat
|
| Row-Crop tractor |
| Built in Winnipeg, Manitoba, Canada |
| Original price was $103,000 in 2000 |
| Fiat G210 Power |
| Engine | 210 hp
156.6 kW
|
| PTO (claimed) | 180 hp
134.2 kW
|
| Drawbar (tested) | 166.3 hp
124.0 kW
|
| PTO (tested) | 200.6 hp
149.6 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Capacity |
| Fuel | 110 gal
416.4 L
|
| Hydraulic system | 36.9 gal
139.7 L
|
| Front hubs | 1.7 qts (each)
1.6 L
|
| Front diff. | 13 qts
12.3 L
|
| Hydraulics |
| Type | closed center load sensing
|
| Capacity | 36.9 gal
139.7 L
|
| Pressure | 2750 psi
189.6 bar
|
| Valves | 3
|
| Pump flow | 24 gpm
90.8 lpm
|
| Total flow | 31 gpm
117.3 lpm
|
| | 55 gpm (MegaFlow optional)
208.2 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift | 12500 lbs
5670 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 1000 (1.375)
|
| Engine RPM | 1000@1903
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 130
|
| Batteries | 2
|
| Battery CCA | 950
|
| Battery volts | 12
|
| References |
 |
| G170, G190, G210, G240 - The Pride of the Field published in 1994, by Fiat |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 13, 2019 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Fiat G210 photos...
