Production | |
Distributor | John Deere |
Manufacturer | Goldini |
Orchard/Vineyard tractor | |
Built in Italy |
John Deere 40R Engine | |
Lombardini 1.6L 3-cyl diesel | |
Fuel tank | 5.8 gal 22.0 L |
Engine details ... |
John Deere 40R Power | |
Engine | 33 hp 24.6 kW |
PTO (claimed) | 28 hp 20.9 kW |
Mechanical | |
Four-wheel drive |
Photos | |
No photos of the John Deere 40R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Tractor hitch | |
Rear Type | IN |
Rear lift (at ends) | 2205 lbs 1000 kg |
Power Take-off (PTO) | |
Rear PTO Type | 540/540E |
Dimensions & Tires | |
Weight | 2513 lbs 1139 kg |
Full dimensions and tires ... |
Electrical | |
Ground | negative |
Charging system | alternator |
Charging amps | 55 |
Battery volts | 12 |
References | |
Milenio 20A, 40A Y 40R published in 2003, by John Deere |
