John Deere 75C


No photo available
2005 - 2015
Milenio C Series
Compact Utility tractor
Goldini built
Series map:
70C
75C
52.2kw
55.9kw
Production
DistributorJohn Deere
ManufacturerGoldini
Compact Utility tractor
Built in Italy
John Deere 75C Engine
VM Motori 3.0L 4-cyl diesel
Fuel tank13.2 gal
50.0 L
Engine details ...
John Deere 75C Power
Engine (gross)75 hp
55.9 kW
Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post mid-mount folding ROPS. Cab optional.
Photos
No photos of the John Deere 75C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2611 psi
180.0 bar
Pump flow10.3 gpm
39.0 lpm
Tractor hitch
Rear TypeII/I
Rear lift (at ends)5071 lbs
2300 kg
Rear lift (at 24"/610mm)3197 lbs
1450 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/540E
Engine RPM540@2430
 540E@1874
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
References
75C references literature
Serie Milenio published in 2010, by John Deere
