John Deere 50C


No photo available
2005 - 2015
Milenio C Series
Compact Utility tractor
Goldini built
Series map:
45C
50C
60C
33.6kw
36.5kw
43.3kw
Production
DistributorJohn Deere
ManufacturerGoldini
Compact Utility tractor
Built in Italy
John Deere 50C Engine
VM Motori 2.1L 3-cyl diesel
Fuel tank13.2 gal
50.0 L
Engine details ...
John Deere 50C Power
Engine (gross)49 hp
36.5 kW
Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post mid-mount folding ROPS.
Photos
No photos of the John Deere 50C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2611 psi
180.0 bar
Pump flow10.3 gpm
39.0 lpm
Tractor hitch
Rear TypeII/I
Rear lift (at ends)5071 lbs
2300 kg
Rear lift (at 24"/610mm)3197 lbs
1450 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/540E
Engine RPM540@2430
 540E@1874
Dimensions & Tires
Wheelbase66.5 inches
168 cm
Weight4189 lbs
1900 kg
Front tire240/70R16
Rear tire320/70R24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
References
50C references literature
Serie Milenio published in 2010, by John Deere
