John Deere 3038R
|
|
| Production | |
| Manufacturer | John Deere |
| Compact Utility tractor | |
| John Deere 3038R Engine | |
| Yanmar 1.5L 3-cyl diesel | |
 Engine details ... |
| John Deere 3038R Transmissions | |
| hydrostatic | |
| 12-speed power shuttle | |
 Transmission details ... |
| John Deere 3038R Power | |
| Engine (gross) | 37.1 hp 27.7 kW |
| Engine (net) | 36.2 hp 27.0 kW |
| PTO (claimed) | 30 hp 22.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional. | |
| Photos | |
| No photos of the John Deere 3038R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| ROPS Fuel | 13.5 gal 51.1 L |
| Cab Fuel | 11.9 gal 45.0 L |
| Hydraulic system | 6.8 gal 25.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 6.8 gal 25.7 L |
| Pump flow | 8.6 gpm 32.6 lpm |
| Total flow | 13.9 gpm 52.6 lpm |
| Steering flow | 5.3 gpm 20.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 2531 lbs 1148 kg |
| Rear lift (at 24"/610mm) | 2202 lbs 998 kg |
| Front Hitch | 0/I OptOptional |
| Front lift (at ends) | 2430 lbs 1102 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent *Standard with hydrostatic, optional with PowrReverser. |
| Mid PTO Type | 2100 |
| Front PTO | independent OptOptional |
| Front PTO Type | 2100 |
| Dimensions & Tires | |
| Wheelbase | 68 inches 172 cm |
| Weight | 3086 to 3748 pounds |
| Front tire | 7.00-14 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Compact Utility Tractors published in 2016, by John Deere |
