GBT GBT-3000


GBT GBT-3000 tractor photo
1976 - 1978
Utility tractor
Production
ManufacturerGBT
Utility tractor
Built in Madison, Wisconsin, USA
Original price was $4,650 in 1976
GBT GBT-3000 Engine
Continental 0.8L 4-cyl gasoline
Engine details ...
GBT GBT-3000 Power
Engine27 hp
20.1 kW
Mechanical
Two-wheel drive
Power steering
Hydraulic disc brakes
Open operator station.
Photos
No photos of the GBT GBT-3000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel7.75 gal
29.3 L
Hydraulic system0.7 gal
2.6 L
Hydraulics
Typeopen center
Capacity0.7 gal
2.6 L
Pressure2000 psi
137.9 bar
Pump flow8 gpm
30.3 lpm
Tractor hitch
Rear TypeI
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase70.5 inches
179 cm
Weight2500 lbs
1134 kg
Front tire5.00x15
Rear tire12.4x24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
GBT-3000 references literature
GBT-3000 published in 1976
GBT-3000 Operator's Manual published in 1976
