John Deere 5125R


John Deere 5125R tractor photo
2017 -
5R Series
Utility tractor
Series map:
5115R
5125R
115.0hp
125.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price was $99,029 in 2019
John Deere 5125R Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5125R Power
Engine125 hp
93.2 kW
Open center PTO (claimed)110 hp
82.0 kW
PFC PTO (claimed)115 hp
85.8 kW
PTO (tested)124.57 hp
92.9 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 5125R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel38 gal
143.8 L
Exhaust fluid (DEF)2.9 gal
11.0 L
Open center Hydraulic system11.75 gal
44.5 L
PFC Hydraulic system12.5 gal
47.3 L
Hydraulics
Open center Typeopen center
PFC Typepressure-flow compensated
Open center Capacity11.75 gal
44.5 L
PFC Capacity12.5 gal
47.3 L
Pressure2900 psi
200.0 bar
Open center SCV flow19.3 gpm
73.1 lpm
PFC SCV flow26.4 gpm
99.9 lpm
Open center Total flow25.5 gpm
96.5 lpm
PFC Total flow39 gpm
147.6 lpm
Open center Steering flow6.2 gpm
23.5 lpm
PFC Steering flow8.1 gpm
30.7 lpm
Tractor hitch
Rear TypeII/I
Controlelectro-hydraulic draft sensing
Rear lift (at ends)7158 lbs
3246 kg
 8157 lbsOptOptional
3700 kg
Rear lift (at 24"/610mm)6979 lbs
3165 kg
 7868 lbsOptOptional
3568 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
Engine RPM540@2100
 540E@1645
 1000@2103
Dimensions & Tires
Wheelbase88.6 inches
225 cm
Weight9811 lbs
4450 kg
Front tire12.4R24
Rear tire18.4R30
Full dimensions and tires ...
5125R Serial Numbers
Location:Serial number plate on the right side of the 5125R frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Battery CCA950
Battery volts12
References
5125R references literature
5R Series Tractors published in 2018, by John Deere
Get a load of Our new 5R options published in 2018, by John Deere
