Kubota M7-172
| | 2018 - 2020 |
| M7-2 Series | | Row-Crop tractor |
|
Series map:
M7-152
M7-172
111.9kw
126.8kw
| Production |
| Manufacturer | Kubota
|
| Row-Crop tractor |
| Built in Bierne, France |
| Kubota M7-172 Power |
| Engine (gross) | 170 hp
126.8 kW
|
| Engine (max) | 175 hp
130.5 kW
|
| Drawbar (tested) | 118.7 hp
88.5 kW
|
| PTO (tested) | 147.26 hp
109.8 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Kubota M7-172 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| | closed center OptOptional
|
| Pump flow | 21.1 gpm (open center)
79.9 lpm
|
| | 29 gpm (closed center)
109.8 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Control | lower-link draft sensing
|
| Rear lift (at ends) | 20723 lbs
9399 kg
|
| Front lift | 8598 lbs
3900 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Engine RPM | 540E@1608
|
| | 540@2005
|
| | 1000E@1600
|
| | 1000@1995
|
| Front PTO | independent
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| M7002 Series published in 2018, by Kubota |
| M7-2 Series published in 2021, by Kubota |
