Tractors > Claas > Axion 840

Claas Axion 840 Tests



Claas Axion 840 tractor photo
2018 -
Axion 800 Series
Row-Crop tractor
Series map:
Axion 830
Axion 840
Axion 850
215.0hp
230.0hp
245.0hp
OCED Tractor Test 2181
Axion 840 fuel use from test 1105
OCED Tractor Test 2181
Diesel IVT 4WD
September 25 - 29, 2017
Link: OCED Tractor Test 2181 file
PTO performance
Power at rated engine speed217.69 hp
162.3 kW
Fuel use12.0 gal/hour
45.4 l/hour
Power at rated PTO speed234.45 hp
174.8 kW
Fuel use12.5 gal/hour
47.3 l/hour
Drawbar performance
Max power188.5 hp
140.6 kW
Fuel use12.0 gal/hour
45.4 l/hour
Pull at 9 KPH
Max pull22001 lbs
9979 kg
Pull at 4 KPH
