RK Tractors RK74PSC
|
|
| Production | |
| Distributor | RK Tractors (a part of Rural King) |
| Manufacturer | TYM |
| Utility tractor | |
| Original price was $37,999 in 2018 | |
| RK Tractors RK74PSC Engine | |
| Deutz 2.9L 4-cyl diesel | |
| Fuel tank | 23.8 gal 90.1 L |
 Engine details ... | |
| RK Tractors RK74PSC Transmission | |
| 16-speed power shuttle | |
 Transmission details ... |
| RK Tractors RK74PSC Power | |
| Engine (gross) | 74 hp 55.2 kW |
| PTO (claimed) | 64.1 hp 47.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Cab standard with air-conditioning. |
| Hydraulics | |
| Type | open center |
| Pump flow | 10.3 gpm 39.0 lpm |
| Total flow | 16.1 gpm 60.9 lpm |
| Steering flow | 5.8 gpm 22.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 5115 lbs 2320 kg |
| Rear lift (at 24"/610mm) | 3414 lbs 1548 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/750 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 86.1 inches 218 cm |
| Weight | 6052 lbs 2745 kg |
| Front tire | 11.2-24 |
| Rear tire | 19.6-30 |
 Full dimensions and tires ... | |
| RK Tractors RK74PSC attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| RK74 Power Shuttle Operator's Manual |
