Branson 4815H
|
|
| Production | |
| Manufacturer | Branson (a part of TYM) |
| Compact Utility tractor | |
| Branson 4815H Engine | |
| Kukje 2.3L 4-cyl diesel | |
| Fuel tank | 7.1 gal 26.9 L |
 Engine details ... | |
| Branson 4815H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Branson 4815H Power | |
| Engine | 47 hp 35.0 kW |
| PTO (claimed) | 40 hp 29.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Two-post folding ROPS. |
| Photos | |
 | |
 Branson 4815H photos... | |
| Hydraulics | |
| Pump flow | 8.7 gpm 32.9 lpm |
| Steering flow | 4.7 gpm 17.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 3306 lbs 1499 kg |
| Rear lift (at 24"/610mm) | 2420 lbs 1097 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 65.7 inches 166 cm |
| Weight | 3278 lbs 1486 kg |
| Front tire | 7-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| 15 Series published in 2019, by Branson |
