Tractors > John Deere > 5125ML

John Deere 5125ML



John Deere 5125ML tractor photo
2018 -
Orchard/Vineyard tractor
Series map:
5115ML
5125ML
115.0hp
123.2hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
John Deere 5125ML Engine
John Deere 4.5L 4-cyl diesel
Fuel tank38 gal
143.8 L
Exhaust fluid (DEF)3.2 gal
12.1 L
Engine details ...
John Deere 5125ML Transmissions
16-speed four-speed power shift
32-speed four-speed power shift
Transmission details ...
John Deere 5125ML Power
Engine (gross)123.2 hp
91.9 kW
PTO (claimed)115 hp
85.8 kW
Drawbar (tested)97.00 hp
72.3 kW
PTO (tested)118.68 hp
88.5 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Manual steering
Hydraulic wet disc brakes
Two-post ROPS.
Photos
No photos of the John Deere 5125ML are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Rear valves3
Mid valves0 to 2
Pump flow31 gpm
117.3 lpm
SCV flow26.4 gpm
99.9 lpm
Tractor hitch
Rear TypeII
Rear lift6975 lbs
3163 kg
 7868 lbsOptOptional
3568 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/540E/1000
Engine RPM540@2100
 540E@1645
 1000@2103
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight8740 lbs
3964 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5125ML references literature
Specialty Series published in 2020, by John Deere
