John Deere 5090EL


John Deere 5090EL tractor photo
2018 -
Orchard/Vineyard tractor
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Variants
5090Eutility
5090ELlow-profile
John Deere 5090EL Engine
John Deere 4.5L 4-cyl diesel
Fuel tank29.7 gal
112.4 L
Engine details ...
John Deere 5090EL Transmissions
12-speed power shuttle
24-speed power shuttle
Transmission details ...
John Deere 5090EL Power
Engine (gross)90 hp
67.1 kW
PTO (claimed)75 hp
55.9 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockmechanical
Power steering
Hydraulic wet disc brakes
Two-post foldable ROPS.
Photos
No photos of the John Deere 5090EL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves2 to 3
Mid valves2 to 3
Pump flow22.5 gpm
85.2 lpm
SCV flow15.9 gpm
60.2 lpm
Tractor hitch
Rear TypeII
Controlmechanical top-link draft sensing
Rear lift (at ends)3213 lbs
1457 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E (1.375)
 540/1000 (1.375)OptOptional
Engine RPM540@2400
 540E@1716
 1000@2400
Dimensions & Tires
Weight7055 lbs
3200 kg
Front tire12.5/80-18
Rear tire19.5L-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
5090EL references literature
Specialty Series published in 2020, by John Deere
