Kubota B2231
| | 2018 - |
| B2 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Kubota B2231 Power |
| Engine (gross) | 22.7 hp
16.9 kW
|
| Engine (net) | 20.4 hp
15.2 kW
|
| PTO (claimed) | 16.8 hp
12.5 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Pressure | 2347 psi
161.8 bar
|
| Total flow | 8.7 gpm
32.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 2138 lbs
969 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2500 (Kubota 10-tooth #5)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on November 5, 2018 |
