Tractors > Kubota > B3030

Kubota B3030



Kubota B3030 tractor photo
2007 - 2013
B30 Series
Compact Utility tractor
Series map:
B2530
B3030
18.4kw
21.9kw
Production
ManufacturerKubota
Compact Utility tractor
Kubota B3030 Engine
Kubota 1.5L 4-cyl diesel
Fuel tank8.2 gal
31.0 L
Engine details ...
Kubota B3030 Transmission
hydrostatic
Transmission details ...
Kubota B3030 Power
Engine (gross)29.4 hp
21.9 kW
Engine (net)26.4 hp
19.7 kW
PTO (claimed)22.7 hp
16.9 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the Kubota B3030 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2205 psi
152.0 bar
Pump flow5.2 gpm
19.7 lpm
Total flow9.1 gpm
34.4 lpm
Steering flow3.9 gpm
14.8 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2138 lbs
969 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2592
Mid PTOoptional
Mid PTO Type2500 (Kubota 10-tooth #5)
Engine RPM2500@2600
Dimensions & Tires
Wheelbase65.6 inches
166 cm
Weight1852 to 2282 pounds
Front tire7-12
Rear tire12.4-16
Full dimensions and tires ...
B3030 Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above and forward of the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery volts12
