Challenger MT738
| | 2018 - |
| MT700 Series | | Agricultural Crawler tractor |
|
Series map:
MT738
MT740
374.0hp
400.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Agricultural Crawler tractor |
| Built in Jackson, Minnesota, USA |
| Challenger MT738 Power |
| Engine (gross) | 374 hp
278.9 kW
|
| PTO (claimed) | 284 hp
211.8 kW
|
| Drawbar (tested) | 270.16 hp
201.5 kW
|
| PTO (tested) | 324.64 hp
242.1 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Challenger MT738 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | load sensing
|
| Valves | 4 to 6
|
| Pump flow | 58 gpm
219.5 lpm
|
| | 116 gpm*With optional dual pumps.
439.1 lpm
|
| Tractor hitch |
| Rear Type | III/IVN
|
| Rear lift | 19000 lbs
8618 kg
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| References |
 |
| MT700 Series published in 2017, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on October 20, 2022 |
