Tractors > Kubota > JB13

Kubota JB13



No photo available
2006 - 2008
JB Bullstar Series
Sub-Compact Utility tractor
Series map:
JB11
JB13
JB14
7.7kw
9.6kw
10.7kw
Production
ManufacturerKubota
Sub-Compact Utility tractor
Variants
JB13wheeled
JB13-PChalf-track
Kubota JB13 Engine
Kubota 0.7L 3-cyl diesel
Fuel tank3.7 gal
14.0 L
Engine details ...
Kubota JB13 Transmission
6-speed
Transmission details ...
Kubota JB13 Power
Engine12.9 hp
9.6 kW
Mechanical
Four-wheel drive
Steeringmanual
Steeringpower OptOptional
Wet disc brakes
Two-post ROPS.
Photos
No photos of the Kubota JB13 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0
Power Take-off (PTO)
Rear PTO540 (1.375)
Rear PTO Type551:2600
 967:2600
Dimensions & Tires
Wheelbase50 inches
127 cm
Weight1213 lbs
550 kg
Front tire4.00-12
Rear tire7-16
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
