| 1995 - 2001 |
MD Series | Utility tractor |
|
Series map:
MD77
MD87
56.7kw
64.0kw
Transmission options |
16-speed |
24-speed creeper |
16-speed partial power shift |
Transmission |
Gears | 16 forward and reverse
|
Four gears (1-4) in two ranges (low/high) with additional two-range shift. |
Speeds |
|
Transmission |
Type | creeper
|
Gears | 24 forward and reverse
|
Optional creeper range added to basic transmission. |
Speeds |
|
Transmission |
Type | partial power shift
|
Gears | 16 forward and reverse
|
Eight gears in two ranges. Optional creeper range available. |
