Kubota GL321
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Kubota GL321 Engine | |
| Kubota 1.5L 3-cyl diesel | |
| Fuel tank | 9.25 gal 35.0 L |
 Engine details ... | |
| Kubota GL321 Transmissions | |
| 16-speed gear | |
| 16-speed power shift | |
 Transmission details ... |
| Kubota GL321 Power | |
| Engine | 32.6 hp 24.3 kW |
| PTO (claimed) | 29.6 hp 22.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post ROPS. Cab optional. |
| Photos | |
| No photos of the Kubota GL321 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 6.3 gpm 23.8 lpm |
| Tractor hitch | |
| Rear Type | JIS1 |
| Rear lift | 1995 lbs 904 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 557@2800 |
| 778@2800 | |
| 966@2800 | |
| 1279@2800 | |
| -783@2800 | |
| Dimensions & Tires | |
| Wheelbase | 68.9 inches 175 cm |
| Weight | 2822 to 3186 pounds |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| GL (T0270-1920-8) published in 1996 | |
| Grandel 1 Plus published in 1994, by Kubota |
