Nuffield DM-4 Universal
|
|
| Production | |
| Manufacturer | Nuffield |
| Utility tractor | |
| Built in Birmingham, England | |
| Nuffield DM-4 Engine | |
| BMC 3.4L 4-cyl diesel | |
| Fuel tank | 16.8 gal 63.6 L |
 Engine details ... | |
| Nuffield DM-4 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Nuffield DM-4 Power | |
| Engine | 45 hp 33.6 kW |
| Drawbar (claimed) | 40.5 hp 30.2 kW |
| Belt (claimed) | 42.7 hp 31.8 kW |
| Drawbar (tested) | 39.44 hp 29.4 kW |
| PTO (tested) | 45.27 hp 33.8 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Independent mechanical contracting band brakes | |
| Open operator station. |
| Photos | |
 | |
 Nuffield DM-4 photos... | |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 528@1400 |
| Dimensions & Tires | |
| Wheelbase | 78 inches 198 cm |
| Weight | 5,560 lbs 2522 kg |
| Front tire | 6.00-16 |
| Rear tire | 11.00-36 |
 Full dimensions and tires ... | |
| References | |
 | |
| The Nuffield Universal Tractor published in 1956 | |
| The Nuffield Universal Tractor published in 1956 | |
| The Nuffield Universal Tractor published in 1956 |
