SAME Explorer 70C
|
|
| Production | |
| Manufacturer | SAME |
| Agricultural Crawler tractor | |
| SAME Explorer 70C Engine | |
| SAME 4.0L 4-cyl diesel | |
| Fuel tank | 26.4 gal 99.9 L |
 Engine details ... | |
| SAME Explorer 70C Transmission | |
| 8-speed shuttle | |
 Transmission details ... |
| SAME Explorer 70C Power | |
| Engine | 70 hp 52.2 kW |
| PTO (claimed) | 61 hp 45.5 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | spur gear |
| Band brakes | |
| Four-post ROPS. | |
| Photos | |
| No photos of the SAME Explorer 70C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2538 psi 175.0 bar |
| Valves | 3 |
| Pump flow | 10 gpm 37.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | top-link draft sensing |
| Rear lift (at ends) | 6393 lbs 2899 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540/1000 |
| Dimensions & Tracks | |
| Wheelbase | 62 inches 157 cm |
| Weight | 7716 lbs 3499 kg |
| 12.2-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| References | |
 | |
| Explorer 70-80-90 C Ergomatic published in 2003, by SAME |
