SAME Frutteto II 85
|
|
| Production | |
| Manufacturer | SAME |
| Orchard/Vineyard tractor | |
| SAME Frutteto II 85 Engine | |
| SAME 4.0L 4-cyl diesel | |
| Fuel tank | 22 gal 83.3 L |
 Engine details ... | |
| SAME Frutteto II 85 Transmissions | |
| 12-speed partially synchronized | |
| 16-speed creeper | |
 Transmission details ... |
| SAME Frutteto II 85 Power | |
| Engine | 85 hp 63.4 kW |
| PTO (claimed) | 78 hp 58.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab optional with air-conditioning. | |
| Photos | |
| No photos of the SAME Frutteto II 85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2650 psi 182.7 bar |
| Valves | 1 to 3 |
| Pump flow | 8.7 gpm 32.9 lpm |
| 16 gpmOptOptional 60.6 lpm | |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift (at ends) | 6614 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | dry disc |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 82 inches 208 cm |
| Weight | 5450 lbs 2472 kg |
| Front tire | 7.50x18 |
| Rear tire | 14.9x24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 55 |
| Cab Charging amps | 65 |
| Battery volts | 12 |
| Battery AH | 100 |
| References | |
 | |
| SAME Tractors that are true specialists published by AGCO |
