Zetor Proxima 100
|
|
| Production | |
| Manufacturer | Zetor |
| Utility tractor | |
| Built in Brno, Czech Republic | |
| Zetor Proxima 100 Engine | |
| Zetor 4.2L 4-cyl diesel | |
 Engine details ... |
| Zetor Proxima 100 Transmissions | |
| 10-speed synchromesh | |
| 12-speed synch shuttle | |
| 20-speed creeper | |
 Transmission details ... |
| Zetor Proxima 100 Power | |
| Engine (net) | 96 hp 71.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with optional air-conditioning. | |
| Photos | |
| No photos of the Zetor Proxima 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Valves | 1 |
| Total flow | 13.2 gpm 50.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position control and mechanical top-link draft sensing |
| Rear lift | 9442 lbs 4282 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| 540/540E | |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 91.4 inches 232 cm |
| 4WD Wheelbase | 88 inches 223 cm |
| Weight | 6900 to 8003 pounds |
| Front tire | 7.5-16 |
| 2WD Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| Zetor Proxima 100 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| References | |
 | |
| Proxima and Poxima Power published by Zetor |
