New Holland T8.380 SmartTrax
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Half-track Crawler tractor | |
| Original price was $387,743 in 2016 with powershift | |
| Variants | |
| T8.380 | wheeled tractor |
| T8.380 SmartTrax | half-track |
| New Holland T8.380 SmartTrax Engine | |
| FPT 8.7L 6-cyl diesel | |
| CVT Fuel tank | 163 gal 617.0 L |
| FPS Fuel tank | 179 gal 677.5 L |
| Exhaust fluid (DEF) | 26 gal 98.4 L |
 Engine details ... | |
| New Holland T8.380 SmartTrax Transmissions | |
| 18-speed full power shift | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| New Holland T8.380 SmartTrax Power | |
| Engine (gross) | 311 hp 231.9 kW |
| Engine (max) | 382 hp 284.9 kW |
| PTO (claimed) | 265 hp 197.6 kW |
| Drawbar (tested) | 227.28 hp 169.5 kW |
| PTO (tested) | 317.66 hp 236.9 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | half-track |
| Final drives | inboard planetary |
| Wet disc brakes | |
| Cab standard with air-conditioning. Intellisteer ready | |
| Photos | |
| No photos of the New Holland T8.380 SmartTrax are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center pressure-flow compensating (PFC) |
| Valves | 4 to 5 |
| Pump flow | 43 gpm 162.8 lpm |
| 73 gpm*Optional, MegaFlow rate. 276.3 lpm | |
| Tractor hitch | |
| Rear Type | III/IIIN |
| IVN/III | |
| Control | electronic lower-link draft sensing |
| Rear lift | 19900 lbs 9026 kg |
| Drawbar | Cat. 3 |
| Cat. 4 OptOptional | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| 540/1000 OptOptional | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 140 inches 355 cm |
| Weight | 35788 lbs 16233 kg |
| Front tire | 380/80R42 |
| Rear tire | tracks |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| Genesis T8 Series Tractors published in 2015, by New Holland |
