Challenger MT535E
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Row-Crop tractor | |
| Built in Jackson, Minnesota, USA | |
| Variants | |
| 7716 | similar Massey Ferguson model |
| Challenger MT535E Engine | |
| AGCO Power 6.6L 6-cyl diesel | |
 Engine details ... |
| Challenger MT535E Transmissions | |
| 24-speed six-speed power shift | |
| continuously-variable transmission (CVT) | |
 Transmission details ... |
| Challenger MT535E Power | |
| Engine (gross) | 150 hp 111.9 kW |
| Engine (max) | 185 hp 138.0 kW |
| PTO (claimed) | 125 hp 93.2 kW |
| Drawbar (tested) | 125.1 hp 93.3 kW |
| PTO (tested) | 154.9 hp 115.5 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. Auto-Guide 3000 | |
| Photos | |
| No photos of the Challenger MT535E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 80 gal 302.8 L |
| Exhaust fluid (DEF) | 8 gal 30.3 L |
| Hydraulic system | 15.9 gal (AP6) 60.2 L |
| 26.4 gal (CVT) 99.9 L | |
| Hydraulics | |
| Type | closed-center load sensing |
| Capacity | 15.9 gal (AP6) 60.2 L |
| 26.4 gal (CVT) 99.9 L | |
| Pressure | 2900 psi 200.0 bar |
| Valves | 3 or 4 |
| SCV flow | 26.4 gpm 99.9 lpm |
| Total flow | 29 gpm 109.8 lpm |
| 50 gpm*Optional with CVT 189.2 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 8900 lbs 4037 kg |
| 15500 lbs*Lift capacity with CVT transmission. 7030 kg | |
| Front Hitch | II |
| Front lift (at ends) | 6200 lbs 2812 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| 540/540E/1000/1000E OptOptional | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MT500E Series Tractors published in 2015, by AGCO |
