Challenger MT525E


Challenger MT525E tractor photo
2015 - 2020
MT500E Series
Row-Crop tractor
Series map:
MT515E
MT525E
MT535E
130.0hp
140.0hp
150.0hp
Production
ManufacturerChallenger (a part of AGCO)
Row-Crop tractor
Built in Jackson, Minnesota, USA
Variants
7715similar Massey Ferguson model
Challenger MT525E Engine
AGCO Power 6.6L 6-cyl diesel
Engine details ...
Challenger MT525E Transmissions
16-speed four-speed power shift
24-speed six-speed power shift
continuously-variable transmission (CVT)
Transmission details ...
Challenger MT525E Power
Engine (gross)140 hp
104.4 kW
Engine (max)175 hp
130.5 kW
PTO (claimed)120 hp
89.5 kW
Drawbar (tested)121.2 hp
90.4 kW
PTO (tested)148.3 hp
110.6 kW
Performance test details ...
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning. Auto-Guide 3000
Photos
No photos of the Challenger MT525E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel80 gal
302.8 L
Exhaust fluid (DEF)8 gal
30.3 L
Hydraulic system15.9 gal (AP6)
60.2 L
 26.4 gal (CVT)
99.9 L
Hydraulics
Typeclosed-center load sensing
Capacity15.9 gal (AP6)
60.2 L
 26.4 gal (CVT)
99.9 L
Pressure2900 psi
200.0 bar
Valves3 or 4
SCV flow26.4 gpm
99.9 lpm
Total flow29 gpm
109.8 lpm
 50 gpm*
189.2 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)8900 lbs
4037 kg
 15500 lbs*
7030 kg
Front HitchII
Front lift (at ends)6200 lbs
2812 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540/540E/1000/1000E Opt
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
MT525E references literature
MT500E Series Tractors published in 2015, by AGCO
