Branson 3015R
| | 2015 - 2023 |
| 15 Series | | Compact Utility tractor |
|
Series map:
3015R
3515R
30.0hp
35.0hp
| Production |
| Manufacturer | Branson (a part of Kukje)
|
| Compact Utility tractor |
| Built in South Korea |
| Branson 3015R Power |
| Engine | 30 hp
22.4 kW
|
| PTO (claimed) | 20.6 hp
15.4 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the Branson 3015R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 8.7 gpm
32.9 lpm
|
| Steering flow | 4.7 gpm
17.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 3306 lbs
1499 kg
|
| Rear lift (at 24"/610mm) | 2420 lbs
1097 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/540E
|
| 3015R Serial Number Location |
 |
| Serial number plate on the front right side of the main tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| 15 Series published in 2019, by Branson |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 29, 2023 |
