Fendt 716 Vario


Fendt 716 Vario tractor photo
2006 - 2022
Model year
700 Vario Series
Row-Crop tractor
Series map:
714 Vario
716 Vario
718 Vario
107.4kw
121.5kw
135.0kw
Production
ManufacturerFendt (a part of AGCO)
Row-Crop tractor
Fendt 716 Vario Engine
Deutz 6.1L 6-cyl
Fuel tank105.7 gal
400.1 L
Exhaust fluid (DEF)10 gal
37.9 L
Engine details ...
Fendt 716 Vario Transmission
continuously-variable transmission (CVT)
Transmission details ...
Fendt 716 Vario Power
Engine (gross)163 hp
121.5 kW
Engine (net)148 hp
110.4 kW
Engine (max)170 hp
126.8 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Power steering
Wet disc brakes
VisioPlus cab standard with air-conditioning and pneumatic suspension. Variotronic; VarioGuide optional
Photos
No photos of the Fendt 716 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload sensing
Pressure2901 psi
200.0 bar
Rear valves2 to 5
Front valves0 to 2
Pump flow28.8 gpm
109.0 lpm
 40.2 gpm*Standard on Profi and ProfiPlus.
152.2 lpm
 51 gpm*Optional on Profi and ProfiPlus.
193.0 lpm
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/540E/1000/1000E
Front PTO Type1000
Dimensions & Tires
Wheelbase109.6 inches
278 cm
Weight17053 lbs
7735 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps200
Charging volts14
Battery volts12
Battery AH180
References
716 Vario references literature
700 Vario published in 2015, by Fendt
