CaseIH Farmall 55C CVT
|
|
| Production | |
| Manufacturer | CaseIH |
| Compact Utility tractor | |
| Original price | $38,877 (2016 ROPS ) |
| $47,769 (2016 Cab ) | |
| CaseIH Farmall 55C Engine | |
| FPT 2.2L 3-cyl diesel | |
| Fuel tank | 13 gal 49.2 L |
 Engine details ... | |
| CaseIH Farmall 55C Transmission | |
| Continuously Variable Transmission (CVT) | |
 Transmission details ... |
| CaseIH Farmall 55C Power | |
| Engine | 54 hp 40.3 kW |
| PTO (claimed) | 43 hp 32.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional. |
| Photos | |
| No photos of the CaseIH Farmall 55C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 or 2 OptOptional |
| Mid valves | 2 |
| Pump flow | 9.8 gpm 37.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 3541 lbs 1606 kg |
| Rear lift (at 24"/610mm) | 2800 lbs 1270 kg |
| Rear Arms | telescopic link ends |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 73.5 inches 186 cm |
| Weight | 4190 to 4940 pounds |
| Front tire | 8x16 |
| Rear tire | 14.9-24 |
 Full dimensions and tires ... | |
| CaseIH Farmall 55C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 75 |
| Cab Charging amps | 90 |
| Battery volts | 12 |
| References | |
 | |
| C Series Compact Farmall C CVT Series Tractors published in 2016, by CaseIH |
