CaseIH Farmall 40C
|
|
| Production | |
| Manufacturer | CaseIH |
| Compact Utility tractor | |
| Original price | $30,021 (2016 shuttle ROPS ) |
| $37,285 (2016 hydro cab ) | |
| CaseIH Farmall 40C Engine | |
| Shibaura 2.2L 4-cyl diesel | |
| ROPS Fuel tank | 10.5 gal 39.7 L |
| Cab Fuel tank | 12.4 gal 46.9 L |
 Engine details ... | |
| CaseIH Farmall 40C Transmissions | |
| 16-speed synchronized shuttle | |
| hydrostatic | |
 Transmission details ... |
| CaseIH Farmall 40C Power | |
| Engine | 40.2 hp 30.0 kW |
| Shuttle PTO (claimed) | 32.4 hp 24.2 kW |
| Hydro PTO (claimed) | 30.8 hp 23.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional. |
| Photos | |
| No photos of the CaseIH Farmall 40C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 1 or 2 |
| Pump flow | 8.2 gpm 31.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 2756 lbs 1250 kg |
| Rear lift (at 24"/610mm) | 2469 lbs 1119 kg |
| Rear Arms | telescopic link ends |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 73.2 inches 185 cm |
| Weight | 3869 to 4380 pounds |
| Front tire | 9.5x16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| CaseIH Farmall 40C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 85 |
| Battery volts | 12 |
| References | |
 | |
| Farmall C Series Compact Tractor Specifications published in 2014, by CaseIH |
