Ford 6600
| Production |
| Manufacturer | Ford
|
| Built in São Bernardo do Campo, Brazil |
| Ford 6600 Power |
| Engine | 85 hp
63.4 kW
|
| PTO (claimed) | 75 hp
55.9 kW
|
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Steering | mechanical
|
| | hydrostatic power OptOptional
|
| Wet disc brakes |
| Open operator station. |
| Photos |
| No photos of the Ford 6600 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 21.5 gal
81.4 L
|
| Hydraulic system | 14 gal
53.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 14 gal
53.0 L
|
| Pressure | 2646 psi
182.4 bar
|
| Pump flow | 9.7 gpm
36.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift (at 24"/610mm) | 4138 lbs
1876 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1900
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 30
|
| Battery volts | 12
|
| Battery AH | 80
|
| References |
 |
| Ford 6600 published in 1984 |
