Tractors > John Deere > 5075GV

John Deere 5075GV



John Deere 5075GV tractor photo
2016 -
5G Series
Orchard/Vineyard tractor
Series map:
5075GV
5090GV
75.0hp
90.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Variants
5075GNnarrow
5075GVvineyard
John Deere 5075GV Engine
FPT 3.4L 4-cyl diesel
Fuel tank22.7 gal
85.9 L
Engine details ...
John Deere 5075GV Transmissions
24-speed
12-speed
Transmission details ...
John Deere 5075GV Power
Engine (gross)75 hp
55.9 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectrohydraulic
Power steering
Hydraulic wet disc brakes
Two-post foldable mid-mount ROPS. Cab optional with air-conditioning.
Photos
No photos of the John Deere 5075GV are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves0 to 4
Mid valves0 to 4
Pump flow17.6 gpm
66.6 lpm
 7.9 gpm*Optional, third pump.
29.9 lpm
Total flow25.5 gpm
96.5 lpm
 33.4 gpm*With third pump
126.4 lpm
Steering flow7.9 gpm
29.9 lpm
Tractor hitch
Rear TypeII
Controlcenter link draft sensing
Rear lift (at ends)5710 lbs
2590 kg
 6834 lbsOptOptional
3099 kg
Rear Armsfixed ball ends
 adjustable ball ends OptOptional
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical dry disc
 hydraulic wet disc *With PowrReverser transmission.
Rear PTO Type540/540E
Dimensions & Tires
Weight5379 to 6051 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5075GV references literature
Specialty Series published in 2020, by John Deere
