Tractors > John Deere > 5100GN

John Deere 5100GN



John Deere 5100GN tractor photo
2016 -
5G Series
Orchard/Vineyard tractor
Series map:
5090GN
5100GN
90.0hp
100.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
John Deere 5100GN Engine
FPT 3.4L 4-cyl diesel
Fuel tank19.3 gal
73.1 L
 26.8 gal*With optional auxiliary tank
101.4 L
Engine details ...
John Deere 5100GN Transmissions
24-speed
12-speed
Transmission details ...
John Deere 5100GN Power
Engine (gross)100 hp
74.6 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectrohydraulic
Power steering
Hydraulic wet disc brakes
Two-post foldable mid-mount ROPS. Cab optional with air-conditioning.
Photos
No photos of the John Deere 5100GN are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves0 to 4
Mid valves0 to 4
Pump flow17.6 gpm
66.6 lpm
 7.9 gpm*Optional, third pump.
29.9 lpm
Total flow25.5 gpm
96.5 lpm
 33.4 gpm*With third pump
126.4 lpm
Steering flow7.9 gpm
29.9 lpm
Tractor hitch
Rear TypeII
Controlcenter link draft sensing
Rear lift (at ends)5710 lbs
2590 kg
 6834 lbsOptOptional
3099 kg
Rear Armsfixed ball ends
 adjustable ball ends OptOptional
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical dry disc
 hydraulic wet disc *With PowrReverser transmission.
Rear PTO Type540/540E
Dimensions & Tires
Weight5566 to 6558 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5100GN references literature
Specialty Series published in 2020, by John Deere
