Tractors > John Deere > 8400

John Deere 8400



John Deere 8400 tractor photo
1995 - 1999
Model year
8000/8000T Series
Row-Crop tractor
Series map:
8300
8400
222.2hp*
250.0hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Variants
8400wheeled tractor
8400Tcrawler tractor
John Deere 8400 Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
John Deere 8400 Transmission
16-speed full power shift
Transmission details ...
John Deere 8400 Power
PTO (claimed)225 hp
167.8 kW
Drawbar (tested)202.28 hp
150.8 kW
PTO (tested)252.21 hp
188.1 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Differential hydraulic wet disc brakes
CommandView Cab standard. Row-Trak guidance optional.
Photos
No photos of the John Deere 8400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel135 gal
511.0 L
Hydraulic system37 gal
140.0 L
Front hubs3.2 qts (each)
3.0 L
Front diff.11.5 qts
10.9 L
Hydraulics
Typeclosed center pressure-flow compensated (PFC)
Capacity37 gal
140.0 L
Pressure2900 psi
200.0 bar
Valves3 to 5
SCV flow30 gpm
113.6 lpm
Tractor hitch
Rear Type3/3N
Controlelectro-hydraulic draft sensing
Rear lift11,700 lbs
5307 kg
 15,650 lbs (optional)
7098 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
 540/1000 (1.375 optional)
Dimensions & Tires
Wheelbase116.1 inches
294 cm
Weight18709 to 19190 pounds
Front tire14.9R34
Rear tire18.4R46
Full dimensions and tires ...
8400 Serial Number Location
John Deere 8400 serial number location
Serial number plate on the rear of the tractor, above the PTO shaft.
8400 Serial Numbers
19951001
19966001
199710001
199820001
199924001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps140
Batteries2
Battery CCA925
Battery volts12
References
8400 references literature
8000/8000T Series Tractors Product Information Handbook published in 1998, by John Deere
