Tractors > John Deere > 6215

John Deere 6215



No photo available
2003 - 2005
6015 Series
Utility tractor
Series map:
6215
6515
70.1kw
85.8kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6215 Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 6215 Transmissions
12-speed fully synchronized
16-speed power shuttle
Transmission details ...
John Deere 6215 Power
Engine (gross)94 hp
70.1 kW
Engine (net)90 hp
67.1 kW
Engine (max)97 hp
72.3 kW
PTO (claimed)80 hp
59.7 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic wet disc
Power steering
Wet disc brakes
Two-post ROPS. Cab available.
Photos
No photos of the John Deere 6215 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel43.6 gal
165.0 L
2WD Hydraulic system13.7 gal
51.9 L
4WD Hydraulic system14.5 gal
54.9 L
Hydraulics
Typeopen center
2WD Capacity13.7 gal
51.9 L
4WD Capacity14.5 gal
54.9 L
Pressure2540 psi
175.1 bar
Pump flow14.3 gpm
54.1 lpm
Tractor hitch
Rear TypeII/I
Controlmechanical top-link draft sensing
Rear lift8318 lbs
3773 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical wet disc
Rear PTO Type540
 540/1000
Engine RPM540@2124
 1000@2208
Dimensions & Tires
Full dimensions and tires ...
6215 Serial Numbers
Location:Serial number plate on the right side of the tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Charging volts14
Battery volts12
Battery AH90
References
6215 references literature
B-Max Series published in 2011, by McCormick
