Kubota M7040
| | 2007 - 2013 |
|
| Utility tractor |
|
Series map:
M6040
M7040
62.0hp
71.0hp
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Original price was $25,106 in 2011 |
| Variants |
| M7040SU | economy model
|
| M7040HDN | narrow chassis
|
| M7040F | 2WD ROPS sync-shuttle
|
| M7040FC | 2WD cab sync-shuttle
|
| M7040DT | 4WD ROPS sync-shuttle
|
| M7040HD | 4WD ROPS hyd-shuttle
|
| M7040DTC | 4WD cab sync-shuttle
|
| M7040HDC | 4WD cab hyd-shuttle
|
| Kubota M7040 Power |
| Engine (net) | 71 hp
52.9 kW
|
| PTO (claimed) | 64 hp
47.7 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | rear standard
|
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post ROPS with optional canopy. Ultra Grand Cab optional with heat and air-conditioning |
| Photos |
| No photos of the Kubota M7040 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| ROPS, 23.8 Cab} Fuel | 18.5 gal
70.0 L
|
| Hydraulic system | 10.6 gal
40.1 L
|
| Front axle | 8.5 qts
8.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10.6 gal
40.1 L
|
| Pressure | 2770 psi
191.0 bar
|
| Valves | 1 to 3
|
| Pump flow | 11 gpm
41.6 lpm
|
| Total flow | 17.2 gpm
65.1 lpm
|
| Steering flow | 6.1 gpm
23.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift (at ends) | 4,200 lbs
1905 kg
|
| Rear lift (at 24"/610mm) | 3,307 lbs
1500 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2295
|
| Dimensions & Tires |
| Wheelbase | 80.7 inches (4WD ROPS)
204 cm
|
| | 82.1 inches (2WD ROPS)
208 cm
|
| | 83.1 inches (4WD cab)
211 cm
|
| | 84.4 inches (2WD cab)
214 cm
|
| Weight | 4675 to 5470 pounds
|
| Front tire | 7.50-16
|
| Rear tire | 16.9-30 (2WD)
|
 Full dimensions and tires ... |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45 (ROPS)
|
| | 60 (cab)
|
| | 80 (optional)
|
| Battery CCA | 900
|
| Battery volts | 12
|
| References |
 |
| M6040/M7040/M8540/M9540 published in 2018, by Kubota |
| M6040/M7040/M8540/M9540 (3C043-9971-2) published in 2006 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 1, 2015 |
