John Deere 9470RX



John Deere 9470RX tractor photo
2016 - 2021
9R Series
Articulated Crawler tractor
Series map:
9470RX
9520RX
470.0hp
520.0hp
Production
ManufacturerJohn Deere
Articulated Crawler tractor
Built in Waterloo, Iowa, USA
Original price was $497,645 in 2015
Variants
9470Rwheeled 4WD
9470RTcrawler
9470RXarticulated crawler
John Deere 9470RX Engine
John Deere 13.5L 6-cyl diesel
Fuel tank400 gal
1514.0 L
Exhaust fluid (DEF)22 gal
83.3 L
Engine details ...
John Deere 9470RX Transmission
18-speed full power shift
Transmission details ...
John Deere 9470RX Power
Engine (gross)470 hp
350.5 kW
Drawbar (tested)352.69 hp
263.0 kW
PTO (tested)363.62 hp
271.2 kW
Performance test details ...
Mechanical
Drivearticulated-crawler
CommandView III cab standard with suspension and air-conditioning. AutoTrac ready; ISOBUS 11783; JDLink ready
Photos
No photos of the John Deere 9470RX are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center pressure/flow compensated
Valves4 to 8
Pump flow58 gpm
219.5 lpm
 115 gpm*Optional, with second 57GPM pump
435.3 lpm
SCV flow35 gpm
132.5 lpm
 42 gpm*Flow at 19.1mm coupler with high-flow hydraulic option.
159.0 lpm
Tractor hitch
Rear TypeIVN/III OptOptional
 IV/IVN OptOptional
Rear lift15000 lbs
6804 kg
 20000 lbs
9072 kg
DrawbarCat. 4
 Cat. 4 HD OptOptional
 Cat. 5 HD OptOptional
Power Take-off (PTO)
Rear PTOindependent OptOptional
Clutchelectro-hydraulic
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase163.5 inches
415 cm
Weight54000 lbs
24494 kg
30-inch tracks
Full dimensions and tracks ...
9470RX Serial Numbers
Location:The John Deere 9470RX serial number plate on the right side of the tractor frame, just ahead of the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
 240 OptOptional
Charging volts12
Batteries3
Battery CCA925
Battery volts12
References
9470RX references literature
9RX Series Tractors published in 2015, by John Deere
